STORINATOR

Simple to set up and designed for quick access, the Storinator will keep all your files in one convenient, centralized location.

The Storinator can be deployed as a single unit or as a part of a clustered solution. This ultra-dense 4U rackmount server offers easy storage scalability and unmatched performance. Easily scale storage by simply adding more HDDs into a single unit, or adding units as separate servers/part of a cluster.

  • Flexibile


    Available in
    15, 30, 45 and 60 drive
    configurations.

  • Affordable


    The most cost-effective, enterprise storage server on the market.

  • Massive


    Keeps all your files in one convenient, centralized location.

Software

The Storinator is software agnostic. This server offers the freedom to run any software you choose, including Linux, CentOS, Debian, FreeBSD, Windows Server, and NAS software. Storinator servers will also run cluster software such as Ceph.

Support

When you choose a 45Drives storage server you get an extremely reliable, affordable, enterprise product and a whole team to help you every step of the way. Learn More

Models

    BASE ENHANCED TURBO

CPU CPU Model Intel Xeon E3-1220 Intel Xeon Silver 4110
AMD EPYC 7281
Intel Xeon Silver 4110 x2
  CPU Architecture 64-bit 64-bit 64-bit
  CPU Frequency 4-Core 2.1 (base) / 3.1 (turbo) GHz 8-Core 2.1 (base) / 3.0 (turbo) GHz 8-Core 2.1 (base) / 3.0 (turbo) GHz

Memory System Memory 8 GB DDR4 ECC UDIMM 16 GB DDR4 ECC RDIMM 32 GB DDR4 ECC RDIMM
  Total Memory Slots 4 8 8
  Memory Expandable up to 64 GB (16 GB x 4) 512 GB (64 GB x 8) 512 GB (64 GB x 8)

Motherboard Make SuperMicro SuperMicro SuperMicro
  Model Q30, S45, XL60: X11SSM
AV15: X11SSH-CTF
X11SPL
H11-SSL (with AMD CPU)
X11DPL

Power Power Supply Unit 850W ATX Standard
(650W ATX on AV15 Model)
850W ATX Standard 850W ATX Standard
  Redundant Power 1400W 2N Redundant (option) 1400W 2N Redundant (option) 1400W 2N Redundant (option)
(Standard on XL60 Models)

Storage Drive Bays 15, 30, 45 or 60 15, 30, 45 or 60 15, 30, 45 or 60
  Maximum Internal Raw Capacity AV15: 240TB --- Q30: 480TB --- S45: 720TB --- XL60: 960TB
( * using 16 TB Drives )
  Hot Swappable Drive Yes Yes Yes

PCIe PCIe Expansion 1 PCI-E 3.0 x8 (in x16),
1 PCI-E 3.0 x8
2 PCI-E 3.0 x4 (in x8)
2 PCI-E 3.0 x8 (in x16 slot)
4 PCI-E 3.0 x8
1 PCI-E 3.0 x4 (in x8 slot)
2 PCI-E 3.0 x16
3 PCI-E 3.0 x8
1 PCI-E 3.0 x4 (in x8 slot)

Network Ports 1Gbe LAN Port Dual 1Gbe on board Dual 1Gbe on board Dual 1Gbe on board
  10Gbe NIC Option Optional NIC (RJ45 or SFP+)
(Included on all S45 Models)
Optional NIC (RJ45 or SFP+)
(Included on all S45 & XL60 Models)
Optional NIC (RJ45 or SFP+)
(Included on all S45 & XL60 Models)
  25Gbe NIC Option Optional NIC (SFP28) Optional NIC (SFP28) Optional NIC (SFP28)
  40Gbe NIC Option Optional NIC (QSFP+) Optional NIC (QSFP+) Optional NIC (QSFP+)

Chassis Form Factor (RU) 4U 4U 4U
  Dimensions AV15: 20.000"L x 17.125" W x 7.000"H
Q30: 25.875"L x 17.125" W x 7.000"H
S45: 31.500"L x 17.125" W x 7.000"H
XL60: 37.500"L x 17.125" W x 7.000"H
  Weight AV15: 45 LBS (With 15 Drives: 70 LBS)
Q30: 55 LBS (With 30 Drives: 105 LBS)
S45: 65 LBS (With 15 Drives: 140 LBS)
XL60: 80 LBS (With 15 Drives: 180 LBS)
